AGQUA-01 blk

Description

– 50 mm tubes
– 16 mm threads
– Square section of 240 mm between each tube (290 mm outside)
– Taper pin and key assembly
– Angle – 2 directions: 60
– Application: horizontal junction
– Maximum dimensions: 100 cm x 100 cm

Manufactured to ISO DIN 4113 and TÜV standards.
Aluminum alloy structure (EN AW 6082 T6) of 50 mm diameter and 2 mm thickness.
Square section to support larger loads, assembled with conical sleeves.
